ABB UNO-3.0-TL-OUTD-S User Manual

- 74 -
000513AG
7 - Operation
Commissioning
Do not place objects of any kind on the inverter during operation! Do not touch the heat sink
while the inverter is operating! Some parts may be very hot and could cause burns.
Before proceeding with commissioning, make sure you have carried out all the checks and
verications indicated in the section on preliminary checks.
The procedure for commissioning the inverter consists of the following
steps:
• Close the DC disconnect switch to supply the inverter with the photovol-
taic generator voltage.
If the inverter is equipped with a DC disconnect switch (-S models), set
the DC disconnect switch
16
to the ON position.
• When the inverter is connected to the power supply, the display will
show a guided conguration procedure. Press ENTER to set the follow-
ing:
- Inverter date and time
- Selection of grid standard and corresponding display language
.
For the list of available grid standards and the relative details, contact ABB.
From the moment that the grid standard is set, you have 24 hours to make any changes to the
value, after which the “Country Select > Set Std.” functionality is blocked, and the remaining
time will have to be reset in order to have the 24 hours of operation available again in which
to select a new grid standard (follow the procedure "Resetting the remaining time for grid
standard variation" described in the relevant section):
• After having set the Country Standard (grid standard), the message "Ini-
tializing...Please Wait” is displayed. Regardless of the input voltage value,
the inverter displays various messages and changes the behaviour of the
three LEDs
06
:
Input voltage Message on display LED Status Description
Vin < Vstart Waiting Sun
Green = Flashing
Yellow = OFF
Red = OFF
The input voltage is not sufcient to enable connection
to the grid.
Vin > Vstart Missing Grid
Green = Flashing
Yellow = ON
Red = OFF
The input voltage is sufcient to enable connection to the
grid: the inverter waits for the grid voltage to be present
to make the parallel connection.
Config. Wizard
ENTER to START
Time hh:mm
Date DD MMM YYYY
GRID=Xxxxxxxx
Lang=Xxxxxxxx
ENTER
ENTER
