Working with Application Graphs Applications
Agilent 8163A/B, 8164A/B & 8166A/B Mainframes, Sixth Edition 235
How to Use Legends
Legends are used to identify Power Meter channels on the graph in the
following ways:
• Legend numbers that are displayed on the graph.
• Legend texts can be accessed by pressing the [Menu] softkey and moving to
<Legend>.
How to Identify Curves
Legend numbers can be related to the curves they represent in the
following ways:
• For the Agilent 8163A/B Lightwave Multimeter the legend number is displayed
at the same height as the first sample of the power measurement channel on
the right-hand side of the screen.
• For the Agilent 8164A/B Lightwave Measureemnt System, the legend numbers
are disrectly beneath the graph. Each number is the same colour as the curve it
represents.
How to Change the Legend Label
To change the legend label:
1 Press the [Menu] softkey and move to <Legend>. A list of the Power Meter
channels appears that is similar to Figure 138 , where all the Power Meters are
listed numerically with regard to legend number. All legend texts, if you have
not previously edited the legend text, are of the "PM x.y", where x represents
the slot number and y represents the channel number.
You cannot edit a legend label while a measurement is running.
NOTE
