20 Rockwell Automation Publication 2094-UM001J-EN-P - March 2017
Chapter 1 Start
Catalog Number Explanation
Kinetix 6000 (Bulletin 2094) drive catalog numbers and descriptions are listed
in the tables below.
Table 3 - Kinetix 6000 Drive Catalog Numbers
Table 4 - Kinetix 6000 Drive Component Catalog Numbers
IMPORTANT Throughout this publication, when the IAM or AM module catalog number
is followed by -x, for example 2094-BMP5-x, the variable (x) indicates that
the drive module may or may not include the safe torque-off feature.
Integrated Axis Modules (230V)
Cat. No.
(with safe torque-off feature)
Cat. No.
(without safe torque-off feature)
Kinetix 6000, IAM, 200V-class, 3 kW converter, 5 A inverter 2094-AC05-MP5-S 2094-AC05-MP5
Kinetix 6000, IAM, 200V-class, 3 kW converter, 9 A inverter 2094-AC05-M01-S 2094-AC05-M01
Kinetix 6000, IAM, 200V-class, 6 kW converter, 15 A inverter 2094-AC09-M02-S 2094-AC09-M02
Kinetix 6000, IAM, 200V-class, 11 kW converter, 24 A inverter 2094-AC16-M03-S 2094-AC16-M03
Kinetix 6000, IAM, 200V-class, 23 kW converter, 49 A inverter 2094-AC32-M05-S 2094-AC32-M05
Integrated Axis Modules (460V)
Kinetix 6000, IAM, 400V-class, 6 kW converter, 4 A inverter 2094-BC01-MP5-S
(1)
2094-BC01-MP5
Kinetix 6000, IAM, 400V-class, 6 kW converter, 9 A inverter 2094-BC01-M01-S
(1)
2094-BC01-M01
Kinetix 6000, IAM, 400V-class, 15 kW converter, 15 A inverter 2094-BC02-M02-S
(1)
2094-BC02-M02
Kinetix 6000, IAM, 400V-class, 28 kW converter, 30 A inverter 2094-BC04-M03-S
(1)
2094-BC04-M03
Kinetix 6000, IAM, 400V-class, 45 kW converter, 49 A inverter 2094-BC07-M05-S
(2)
2094-BC07-M05
Axis Modules (230V)
Kinetix 6000, AM, 200V-class, 5 A 2094-AMP5-S 2094-AMP5
Kinetix 6000, AM, 200V-class, 9 A 2094-AM01-S 2094-AM01
Kinetix 6000, AM, 200V-class, 15 A 2094-AM02-S 2094-AM02
Kinetix 6000, AM, 200V-class, 24 A 2094-AM03-S 2094-AM03
Kinetix 6000, AM, 200V-class, 49 A 2094-AM05-S 2094-AM05
Axis Modules (460V)
Kinetix 6000, AM, 400V-class, 4 A 2094-BMP5-S
(1)
2094-BMP5
Kinetix 6000, AM, 400V-class, 9 A 2094-BM01-S
(1)
2094-BM01
Kinetix 6000, AM, 400V-class, 15 A 2094-BM02-S
(1)
2094-BM02
Kinetix 6000, AM, 400V-class, 30 A 2094-BM03-S
(1)
2094-BM03
Kinetix 6000, AM, 400V-class, 49 A 2094-BM05-S
(2)
2094-BM05
(1) You can configure the peak inverter current rating of this 460V (series B and C) IAM or AM module for 250% of continuous inverter current.
(2) You can configure the peak inverter current rating of this 460V (series B and C) IAM or AM module for 200% of continuous inverter current. Refer to Peak Enhancement
Specifications on page 74, for more information on drive performance in the peak-enhanced mode.
Drive Components Cat. No.
Integrated power interface (IPIM) module, 400V-class, 15 kW, 24 A (rms) 2094-SEPM-B24-S
Kinetix 6000 shunt module, 200/400V-class, 200 W 2094-BSP2
Kinetix 6000 slot-filler module, 200/400V-class 2094-PRF
