Rockwell Automation Publication 2094-UM001J-EN-P - March 2017 231
DC Common Bus Applications Appendix C
Set the Additional Bus
Capacitance Parameter
In this section you set the Add Bus Cap parameter by using DriveExplorer
software.
The following hardware and software tools are required to provide the
necessary communication link between your personal computer and the
Kinetix 6200 and Kinetix 6500 drive system running DriveExplorer software.
Table 124 - Kinetix 6000 System Requirements
Remove Sercos Communication
Follow these steps to remove (break) Sercos communication.
1. Remove three-phase and control power from the Kinetix 6200 and
Kinetix 6500 drive system.
2. Remove one of the Sercos fiber-optic cables.
Fiber-optic cable connections (Tx and Rx) are on the top of each IAM
and AM module.
3. Re-apply three-phase and control power.
TIP You can also set the Add Bus Cap parameter by changing IDN parameter
values. Refer to Appendix E on page 253
for more information.
TIP You can use this procedure to change other parameters too, the Analog
Output parameters, for example.
Description Cat. No. Version
DriveExplorer software
(1) (2)
(1) Refer to DriveExplorer Getting Results Manual, publication 9306-GR001, for instructions.
(2) Additional information regarding these communication and software tools is available at http://www.ab.com/support/
abdrives.
9306-4EXP02ENE 2.01 or later
Serial to SCANport™ adapter
(2) (3)
(3) Refer to 1203-SSS (series B) FRN 3.xxx User Manual, publication 20COMM-UM001, for instructions.
1203-SSS (Series B) 3.004 or later
Studio 5000 Logix Designer® application
9324-RLD300xxE
21.0 or later
RSLogix 5000® software 15.0 or later
ATTENTION: To avoid personal injury or equipment damage, at least one
end of a Sercos fiber-optic cable must be disconnected from the drive. This
makes sure that motion does not occur while changes are being made to the
Add Bus Cap parameter.
