Rockwell Automation Publication 2094-UM001J-EN-P - March 2017 259
Appendix F
Enhanced Peak Performance
This appendix provides procedures and information, specific to Kinetix® 6000
drive systems, for enabling the peak enhancement feature in each drive.
Before You Begin
The peak current ratings of the Kinetix 6000 460V drives (series A, B, and C) are
configured at the factory as 150% of continuous current. However, you can
program 460V (series B and C) AM modules and the equivalent IAM (inverter)
modules, for up to 250% of continuous inverter current.
To achieve the enhanced peak performance, you must determine the values of
maximum acceleration, deceleration, and torque. This feature is present only in
the Kinetix 6000 (series B and C) drives listed in Table 131
.
Table 131 - Kinetix 6000 Series Change
Topic Page
Before You Begin 259
Enhanced Peak Example 261
Change the Drive Parameter 266
IAM Module
Cat. No.
AM Module
Cat. No.
Peak Current Rating
Series A (inverter) Series B and C (inverter)
2094-BC01-MP5-S 2094-BMP5-S 150% 250%
2094-BC01-M01-S 2094-BM01-S 150% 250%
2094-BC02-M02-S 2094-BM02-S 150% 250%
2094-BC04-M03-S 2094-BM03-S 150% 250%
2094-BC07-M05-S 2094-BM05-S 150% 200%
