Rockwell Automation Publication 2094-UM001J-EN-P - March 2017 73
Connector Data and Feature Descriptions Chapter 4
Input Power Cycle Capability
The power cycle capability is inversely proportional to the system capacitance
(including DC bus follower), but cannot exceed 2 contactor cycles per minute
with up to 4 axes or 1 contactor cycle per minute with 5…8 axes.
The cycle capability also depends on the converter power rating and the total
system capacitance. Refer to Appendix C on page 227
to calculate total system
capacitance.
Table 43 - Maximum Input Power Cycling Specifications (230V)
Table 44 - Maximum Input Power Cycling Specifications (460V)
For example, in a 4 axis system with a 2094-BC02-M02-S IAM module and
2,000 µF total capacitance, the calculated capability is 0.52 x 10,000/2000 =
2.6 cycles per minute. However, this value is reduced to 2.0 by the 4 axes per
system limitation.
Attribute 2094-AC05-MP5-S 2094-AC05-M01-S 2094-AC09-M02-S 2094-AC16-M03-S 2094-AC32-M05-S
Main AC input power cycling
(cycles per minute for 10,000 μf) 0.69 4.30
Attribute 2094-BC01-MP5-S 2094-BC01-M01-S 2094-BC02-M02-S 2094-BC04-M03-S 2094-BC07-M05-S
Main AC input power cycling
(cycles per minute for 10,000 μf) 0.12 0.52 2.15 4.30
