256 Rockwell Automation Publication 2094-UM001J-EN-P - March 2017

Appendix E Changing the Default IDN Parameter Values

8. Click Browse.

9. Select the Bulletin 2094 module to read the MSG instruction.

10. Click OK.

Calculate the New IDN Value

Changing the additional bus capacitance value requires calculations.

Determine the sum of all capacitance values for the follower IAM module,

each AM module, and each IPIM module on the follower IAM power rail.

Refer to Calculate Additional Bus Capacitance on page 229

for more

information.
