Rockwell Automation Publication 2080-UM001B-EN-E - November 2011 29
Appendix
A
Specifications
Micro810 Controllers
General - 2080-LC10-12AWA, 2080-LC10-12QWB, 2080-LC1012DWD, 2080-LC10-12QBB
Attribute 2080-LC10-12AWA 2080-LC10-12QWB 2080-LC1012DWD 2080-LC10-12QBB
Number of I/O 8 Input (4 digital, 4 analog/digital, configurable)
4 Output
Dimensions
HxWxD
91 x 75 x 59 mm
(3.58 x 2.95 x 2.32 in.)
Supply voltage range 85V…263V 20.4…26.4V DC 10.8V…13.2V DC 11.4V..26.4V DC
Supply frequency range
(AC supply)
47…63 Hz N.A.
Voltage range 100…240V AC, 50/60 Hz 24V DC
Class 2
12V DC
Class 2
12/24V DC
Class 2
Power consumption 5V A 3 W
I/O rating Input: 120…240V AC Input: 24V DC, 8 mA Input: 12V DC, 8 mA Input: 24V DC, 8 mA
Output: 24V DC 1A, 25 °C, 24V DC
0.5A 55°C
Output: Relay 00 & 01: 8 A @ 240V AC, B300, R300, General Use
Relay 02 & 03: 4 A @ 240V AC, C300, R150, General Use
Shipping weight,
approx.
0.203 kg (0.448 lb)
Wire size 0.32... 2.1 mm² (22...14 AWG) solid copper wire or
0.32... 1.3 mm² (22...16 AWG) stranded copper wire
rated at 90 °C (194 °F ) insulation max.
Wiring category
(1)
2 - on signal ports
2 - on power ports
Wiring torque 1.085 Nm (8 lb-in)
Wire type use Copper Conductors only
Fuse, type Rated 250V 3.15 A-RADIAL
Enclosure type rating Meets IP20
North American temp
code
T5
Insulation stripping
length
7 mm (0.28 in)
Isolation voltage 250V (continuous), Reinforced
Insulation Type, I/O to Aux and
Network, Inputs to Outputs.
Type tested for 60 s 3250V DC,
I/O to Aux and Network, Inputs
to Outputs
250V (continuous), Reinforced Insulation Type, I/O to
Aux and Network, Inputs to Outputs
Type tested for 60 s at 720V DC, Inputs to Aux and
Network, 3250V DC Outputs to Aux and Network,
Inputs to Outputs
50V (continuous), Reinforced
Insulation Type, I/O to Aux and
Network, Inputs to Outputs
Type tested for 60 s at 720V DC, I/O
to Aux and Network, Inputs to
Outputs
AC input filter setting 16 ms for all embedded inputs
(In CCW, go to the Embedded I/O configuration window to re-configure the filter setting for each input group
(1) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
