Publication 1762-RM001C-EN-P

Communications Instructions 21-9

Configuring a Local

Message

Message Setup Screen

The rung below shows a MSG instruction preceded by conditional logic.

Access the message setup screen by double-clicking Setup Screen.

The RSLogix Message Setup Screen is shown below. This screen is used to

setup “This Controller”, “Target Device”, and “Control Bits”. Descriptions

of each of the elements follow.

0000

B3:0

MSG

Read/Write Message

MSG File MG11:0

Setup Screen

MSG
