Publication 1762-RM001C-EN-P
C-2 System Status File
Status File Overview
The status file (S:) contains the following words:
Address Function Page
S:0 Arithmetic Flags C-3
S:1 Controller Mode C-4
S:2 STI Mode C-9
S:2/9 Memory Module Program Compare C-9
S:2/15 Math Overflow Selection C-10
S:3H Watchdog Scan Time C-10
S:4 Free Running Clock C-10
S:5 Minor Error Bits C-11
S:6 Major Error Code C-13
S:7 Suspend Code C-14
S:8 Suspend File C-14
S:9 Active Nodes (Nodes 0 to 15) C-14
S:10 Active Nodes (Nodes 16 to 31) C-14
S:13, S:14 Math Register C-15
S:15L Node Address C-15
S:15H Baud Rate C-15
S:22 Maximum Scan Time C-15
S:29 User Fault Routine File Number C-16
S:30 STI Set Point C-16
S:31 STI File Number C-16
S:33 Channel 0 Communications C-16
S:35 Last 100 µSec Scan Time C-17
S:36/10 Data File Overwrite Protection Lost C-18
S:37 RTC Year C-18
S:38 RTC Month C-18
S:39 RTC Day of Month C-18
S:40 RTC Hours C-19
S:41 RTC Minutes C-19
S:42 RTC Seconds C-19
S:53 RTC Day of Week C-19
S:57 OS Catalog Number C-20
S:58 OS Series C-20
S:59 OS FRN C-20
S:60 Processor Catalog Number C-20
S:61 Processor Series C-20
S:62 Processor Revision C-20
S:63 User Program Functionality Type C-21
S:64L Compiler Revision - Build Number C-21
S:64H Compiler Revision - Release C-21
