Allen-Bradley PowerFlex 525 User Manual

128 Rockwell Automation Publication 520-UM001A-EN-E - February 2013
Chapter 3 Programming and Parameters
Parameter Cross Reference by Name
Parameter Name No. Parameter Name No. Parameter Name No.
10V Bipolar Enbl 093 DB Resistor Sel 437 DSI Errors 731
2-Wire Mode 064 DB Threshold 438 DSI I/O Act 686
Accel Time 1 041 DC Brake Level 435 DSI I/O Cfg 175
Accel Time 2 442 DC Brake Time 434 Elapsed kWh 021
Accel Time 3 444 DC Brk Time@Strt 436 Elapsed MWh 022
Accel Time 4 446 DC Bus Ripple 380 Elapsed Run Time 019
Accum CO2 Sav 026 DC Bus Voltage 005 Elapsed Time-hr 362
Accum Cost Sav 025 Decel Time 1 042 Elapsed Time-min 363
Accum kWh Sav 024 Decel Time 2 443 EM Brk Off Delay 086
Analog In 0-10V 360 Decel Time 3 445 EM Brk On Delay 087
Analog In 4-20mA 361 Decel Time 4 447 EN Addr Sel 128
Analog In Filter 099 Dig In Status 014 EN Addr Src 684
Analog Out High 089 DigIn TermBlk 02 062 EN Comm Flt Actn 143
Analog Out Sel 088 DigIn TermBlk 03 063 EN Data In 1 153
Anlg In 0-10V Hi 092 DigIn TermBlk 05 065 EN Data In 2 154
Anlg In 0-10V Lo 091 DigIn TermBlk 06 066 EN Data In 3 155
Anlg In mA Loss 097 DigIn TermBlk 07 067 EN Data In 4 156
Anlg In V Loss 094 DigIn TermBlk 08 068 EN Data Out 1 157
Anlg In4-20mA Hi 096 Drive OL Mode 495 EN Data Out 2 158
Anlg In4-20mA Lo 095 Drive Status 006 EN Data Out 3 159
Anlg Loss Delay 098 Drive Temp 027 EN Data Out 4 160
Anlg Out Setpt 090 Drive Type 367 EN Flt Cfg DL 1 147
Auto Rstrt Delay 542 Droop Hertz@ FLA 441 EN Flt Cfg DL 2 148
Auto Rstrt Tries 541 Drv 0 Feedback 708 EN Flt Cfg DL 3 149
Autotune 040 Drv 0 Logic Cmd 705 EN Flt Cfg DL 4 150
Average kWh Cost 052 Drv 0 Logic Sts 707 EN Flt Cfg Logic 145
Average Power 020 Drv 0 Reference 706 EN Flt Cfg Ref 146
Boost Select 530 Drv 1 Addr 171 EN Gateway Act 1 701
Break Frequency 533 Drv 1 Feedback 712 EN Gateway Act 2 702
Break Voltage 532 Drv 1 Logic Cmd 709 EN Gateway Act 3 703
Bus Reg Enable 550 Drv 1 Logic Sts 711 EN Gateway Act 4 704
Cmd Stat Select 122 Drv 1 Reference 710 EN Gateway Cfg 1 137
Com Sts-Emb Enet 683 Drv 2 Addr 172 EN Gateway Cfg 2 138
Comm Loss Action 125 Drv 2 Feedback 716 EN Gateway Cfg 3 139
Comm Loss Time 126 Drv 2 Logic Cmd 713 EN Gateway Cfg 4 140
Comm Sts - DSI 681 Drv 2 Logic Sts 715 EN Idle Flt Actn 144
Comm Sts - Opt 682 Drv 2 Reference 714 EN IP Addr Act 1 693
Comm Write Mode 121 Drv 3 Addr 173 EN IP Addr Act 2 694
Commanded Freq 002 Drv 3 Feedback 720 EN IP Addr Act 3 695
Compensation 547 Drv 3 Logic Cmd 717 EN IP Addr Act 4 696
Contrl In Status 013 Drv 3 Logic Sts 719 EN IP Addr Cfg 1 129
Control Source 012 Drv 3 Reference 718 EN IP Addr Cfg 2 130
Control SW Ver 029 Drv 4 Addr 174 EN IP Addr Cfg 3 131
Control Temp 028 Drv 4 Feedback 724 EN IP Addr Cfg 4 132
Counter Status 364 Drv 4 Logic Cmd 721 EN Missed IO Pkt 730
Counts Per Unit 559 Drv 4 Logic Sts 723 EN Rate Act 685
Current Limit 1 484 Drv 4 Reference 722 EN Rate Cfg 141
Current Limit 2 485 Drv Ambient Sel 554 EN Rx Errors 727
