Allen-Bradley PowerFlex 525 User Manual

Rockwell Automation Publication 520-UM001A-EN-E - February 2013 157
Accessories and Dimensions Appendix B
Product Dimensions
The PowerFlex 525 drive is available in five frame sizes. See PowerFlex 525 Drives
on page 149 for information on power ratings.
10.0 7.5 10.0 7.5 1321-3R18-B 1321-3RA18-B 1321-3R18-B 1321-3RA18-B
15.0 11.0 15.0 11.0 1321-3R25-B 1321-3RA25-B 1321-3R25-B 1321-3RA25-B
20.0 15.0 15.0 11.0 1321-3R35-B (ND)
1321-3R25-B (HD)
1321-3RA35-B (ND)
1321-3RA25-B (HD)
1321-3R25-B 1321-3RA25-B
25.0 18.5 20.0 15.0 1321-3R35-B 1321-3RA35-B 1321-3R35-B 1321-3RA35-B
30.0 22.0 25.0 18.5 1321-3R45-B (ND)
1321-3R35-B (HD)
1321-3RA45-B (ND)
1321-3RA35-B (HD)
1321-3R45-B 1321-3RA45-B
460...600V 50/60 Hz 3-Phase
0.5 0.4 0.5 0.4 1321-3R2-B 1321-3RA2-B 1321-3R2-B 1321-3RA2-B
1.0 0.75 1.0 0.75 1321-3R2-B 1321-3RA2-B 1321-3R2-B 1321-3RA2-B
2.0 1.5 2.0 1.5 1321-3R4-D 1321-3RA4-D 1321-3R4-D 1321-3RA4-D
3.0 2.2 3.0 2.2 1321-3R4-C 1321-3RA4-C 1321-3R4-C 1321-3RA4-C
5.0 3.7 5.0 3.7 1321-3R8-C 1321-3RA8-C 1321-3R8-C 1321-3RA8-C
7.5 5.5 7.5 5.5 1321-3R12-C 1321-3RA12-C 1321-3R12-C 1321-3RA12-C
10.0 7.5 10.0 7.5 1321-3R12-B 1321-3RA12-B 1321-3R12-B 1321-3RA12-B
15.0 11.0 15.0 11.0 1321-3R18-B 1321-3RA18-B 1321-3R18-B 1321-3RA18-B
20.0 15.0 15.0 11.0 1321-3R25-B (ND)
1321-3R18-B (HD)
1321-3RA25-B (ND)
1321-3RA18-B (HD)
1321-3R25-B 1321-3RA25-B
25.0 18.5 20.0 15.0 1321-3R35-C (ND)
1321-3R25-B (HD)
1321-3RA35-C (ND)
1321-3RA25-B (HD)
1321-3R35-C 1321-3RA35-C
30.0 22.0 25.0 18.5 1321-3R35-B (ND)
1321-3R35-C (HD)
1321-3RA35-B (ND)
1321-3RA35-C (HD)
1321-3R35-B 1321-3RA35-B
(1) Normal Duty and Heavy Duty ratings for 15 HP / 11 kW and below are identical
(2) Catalog numbers listed are for 3% impedance. 5% impedance reactor types are also available. See publication 1321-TD001.
(3) Input line reactors were sized based on the NEC fundamental motor amps. Output line reactors were sized based on the VFD rated
output currents.
Bulletin 1321-3R Series Line Reactors
Output Ratings
(1)
Input Line Reactor
(2)(3)
Output Line Reactor
(2)(3)
Normal Duty Heavy Duty
IP00
(Open Style)
IP11
(NEMA/UL Type 1)
IP00
(Open Style)
IP11
(NEMA/UL Type 1)
HP kW HP kW Catalog No. Catalog No. Catalog No. Catalog No.
PowerFlex 525 Drive Weight
Frame Size Weight (kg/lb.)
A1.1 / 2.4
B1.6 / 3.5
C2.3 / 5.0
D3.9 / 8.6
E 12.9 / 28.4
