Rockwell Automation Publication 520-UM001A-EN-E - February 2013 7
Preface
Overview
The purpose of this manual is to provide you with the basic information needed
to install, start-up and troubleshoot the PowerFlex® 525 Adjustable Frequency
AC Drive.
Who Should Use this Manual
This manual is intended for qualified personnel. You must be able to program
and operate Adjustable Frequency AC Drive devices. In addition, you must have
an understanding of the parameter settings and functions.
Recommended
Documentation
All the recommended documentation listed in this section is available online at
http://www.rockwellautomation.com/literature
.
The following publications provide general drive information:
The following publications provide specific PowerFlex 520-Series information on
drive installation, features, specifications, and service:
For information on… See page…
Who Should Use this Manual 7
Recommended Documentation 7
Manual Conventions 8
Drive Frame Sizes 9
General Precautions 9
Catalog Number Explanation 10
Title Publication
Wiring and Grounding Guidelines for Pulse Width Modulated (PWM) AC Drives DRIVES-IN001
Preventive Maintenance of Industrial Control and Drive System Equipment DRIVES-TD001
Safety Guidelines for the Application, Installation and Maintenance of Solid State Control SGI-1.1
A Global Reference Guide for Reading Schematic Diagrams 100-2.10
Guarding Against Electrostatic Damage 8000-4.5.2
Title Publication
PowerFlex 525 AC Drive Specifications 520-TD001
PowerFlex Dynamic Braking Resistor Calculator PFLEX-AT001
PowerFlex AC Drives in Common Bus Configurations DRIVES-AT002
