52 Rockwell Automation Publication 520-UM001A-EN-E - February 2013
Chapter 2 Start Up
Smart Start-Up with Basic
Program Group Parameters
The PowerFlex 525 drive is designed so that start up is simple and efficient. The
Basic Program Group contains the most commonly used parameters. See
Programming and Parameters
on page 57 for detailed descriptions of the
parameters listed here, as well as the full list of available parameters.
Polish Y – –
Tur ki sh Y – –
Czech Y – –
Language HIM/LCD Display RSLogix 5000
(Version 17.0 or greater) /
Logix Designer
(Version 21.0 or greater)
Connected Components
Workbench
(Version 3.0 or greater)
= Stop drive before changing this parameter.
No. Parameter Min/Max Display/Options Default
P030 [Language] 1/15 1 = English
2= Français
3= Español
4 = Italiano
5= Deutsch
6= Japanese
7 = Português
8= Chinese
9 = Reserved
10 = Reserved
11 = Korean
12 = Polish
13 = Reserved
14 = Turkish
15 = Czech
1
Selects the language displayed.
P031 [Motor NP Volts] 10 (for 200V Drives), 20 (for
400V Drives), 25 (for 600V
Drives)/Drive Rated Volts
1V Based on Drive Rating
Sets the motor nameplate rated volts.
P032 [Motor NP Hertz] 15/500 Hz 1 Hz 60 Hz
Sets the motor nameplate rated frequency.
P033 [Motor OL Current] 0.0/(Drive Rated Amps × 2) 0.1 A Based on Drive Rating
Sets the motor nameplate overload current.
P034 [Motor NP FLA] 0.0/(Drive Rated Amps x 2) 0.1 A Drive Rated Amps
Sets the motor nameplate FLA.
P035 [Motor NP Poles] 2/40 1 4
Sets the number of poles in the motor.
P036 [Motor NP RPM] 0/24000 rpm 1 rpm 1750 rpm
Sets the rated nameplate rpm of motor.
P037 [Motor NP Power] 0.00/Drive Rated Power 0.01 kW Drive Rated Power
Sets the motor nameplate power.
P038 [Voltage Class] 2/3 2 = “480V”
3 = “600V”
3
Sets the voltage class of 600V drives. Only applicable
to 600V drives.
P039 [Torque Perf Mode] 0/3 0 = “V/Hz”
1 = “SVC”
2 = “Economize”
3 = “Vector”
1
Selects the motor control mode.
P040 [Autotune] 0/2 0 = “Ready/Idle”
1 = “Static Tune”
2 = “Rotate Tune”
0
Enables a static (not spinning) or dynamic (motor
spinning) autotune.
To Next Page
