Rockwell Automation Publication February - February 2013 57
Chapter 3
Programming and Parameters
This chapter provides a complete listing and description of the PowerFlex 525
parameters. Parameters are programmed (viewed/edited) using either the drive’s
built-in keypad, RSLogix 5000 version 17.0 or greater, Logix Designer version
21.0 or greater, or Connected Components Workbench version 3.0 or greater
software. The Connected Components Workbench software can be used offline
(through USB) to upload parameter configurations to the drive or online
(through Ethernet connection).
Limited functionality is also available when using the Connected Components
Workbench software online (through DSI and serial converter module), a legacy
external HIM, or legacy software online (DriveTools SP™). When using these
methods, the parameter list can only be displayed linearly, and there is no access
to communications option card programming.
For information on... See page...
About Parameters 58
Parameter Groups 58
Basic Display Group 63
Basic Program Group 68
Terminal Block Group 73
Communications Group 85
Logic Group 91
Advanced Display Group 94
Advanced Program Group 98
Network Parameter Group 118
Modified Parameter Group 118
Fault and Diagnostic Group 119
AppView Parameter Groups 126
CustomView Parameter Group 127
Parameter Cross Reference by Name 128
