98 Rockwell Automation Publication 520-UM001A-EN-E - February 2013
Chapter 3 Programming and Parameters
Advanced Program Group
A410 [Preset Freq 0]
A412 [Preset Freq 2]
A414 [Preset Freq 4]
A416 [Preset Freq 6]
A418 [Preset Freq 8]
A420 [Preset Freq 10]
A422 [Preset Freq 12]
A424 [Preset Freq 14]
A411 [Preset Freq 1]
A413 [Preset Freq 3]
A415 [Preset Freq 5]
A417 [Preset Freq 7]
A419 [Preset Freq 9]
A421 [Preset Freq 11]
A423 [Preset Freq 13]
A425 [Preset Freq 15]
Sets the frequency of the drive outputs to the programmed value when selected.
Values Defaults:
Preset Freq 0:
Preset Freq 1:
Preset Freq 2:
Preset Freq 3:
Preset Freq 4:
Preset Freq 5:
Preset Freq 6:
Preset Freq 7...15:
0.00 Hz
5.00 Hz
10.00 HZ
20.00 Hz
30.00 Hz
40.00 Hz
50.00 Hz
60.00 Hz
Min/Max: 0.00/500.00 Hz
Display: 0.01 Hz
Default Accel/Decel Used Preset Input 1
(DigIn TermBlk 05)
Preset Input 2
(DigIn TermBlk 06)
Preset Input 3
(DigIn TermBlk 07)
Preset Input 4
(DigIn TermBlk 08)
Preset Setting 0
(1)
(1) Preset Setting 0 is only available if P047, P049 or P051 [Speed Referencex] is set to 7 “Preset Freq”.
10000
Preset Setting 1 1 1 0 0 0
Preset Setting 2 2 0 1 0 0
Preset Setting 3 2 1 1 0 0
Preset Setting 4 1 0 0 1 0
Preset Setting 5 1 1 0 1 0
Preset Setting 6 2 0 1 1 0
Preset Setting 7 2 1 1 1 0
Preset Setting 8 1 0 0 0 1
Preset Setting 9 1 1 0 0 1
Preset Setting 10 2 0 1 0 1
Preset Setting 11 2 1 1 0 1
Preset Setting 12 1 0 0 1 1
Preset Setting 13 1 1 0 1 1
Preset Setting 14 2 0 1 1 1
Preset Setting 15 2 1 1 1 1
A426 [Keypad Freq] Related Parameter(s): P047, P049, P051
Provides the drive frequency command using the built-in keypad navigation. When P047, P049 or P051 [Speed Referencex] selects 2 “Keypad Freq”, the value set in this parameter
controls the frequency of the drive. The value of this parameter can also be changed when navigating with the keypad by pressing the Up or Down arrow keys.
Values Default: 60.00 Hz
Min/Max: 0.00/500.00 Hz
Display: 0.01 Hz
A427 [MOP Freq]
Provides the drive frequency command using the built-in Motor Operated Potentiometer (MOP).
Values Default: 60.00 Hz
Min/Max: 0.00/500.00 Hz
Display: 0.01 Hz
Frequency is not written to non-volatile storage until drive is powered-down. If both MOP Up and MOP Down are applied at the same time, the inputs are
ignored and the frequency is unchanged.
