Allen-Bradley PowerFlex 525 User Manual

Rockwell Automation Publication 520-UM001A-EN-E - February 2013 149
Appendix B
Accessories and Dimensions
Product Selection
Catalog Number Description
25B - V 2P5 N 1 0 4
Drive Voltage Rating Rating Enclosure HIM Emission Class Version
PowerFlex 525 Drives
Catalog No.
Output Ratings
Input
Voltage Range
Frame
Size
Normal Duty Heavy Duty
Output
Current (A)HP kW HP kW
100...120V AC (-15%, +10%) – 1-Phase Input, 0...230V 3-Phase Output
25B-V2P5N104 0.5 0.4 0.5 0.4 2.5 85...132 A
25B-V4P8N104 1.0 0.75 1.0 0.75 4.8 85...132 B
25B-V6P0N104 1.5 1.1 1.5 1.1 6.0 85...132 B
200...240V AC (-15%, +10%) – 1-Phase Input, 0...230V 3-Phase Output
25B-A2P5N104 0.5 0.4 0.5 0.4 2.5 170...264 A
25B-A4P8N104 1.0 0.75 1.0 0.75 4.8 170...264 A
25B-A8P0N104 2.0 1.5 2.0 1.5 8.0 170...264 B
25B-A011N104 3.0 2.2 3.0 2.2 11.0 170...264 B
200...240V AC (-15%, +10%) – 1-Phase Input with EMC Filter, 0...230V 3-Phase Output
25B-A2P5N114 0.5 0.4 0.5 0.4 2.5 170...264 A
25B-A4P8N114 1.0 0.75 1.0 0.75 4.8 170...264 A
25B-A8P0N114 2.0 1.5 2.0 1.5 8.0 170...264 B
25B-A011N114 3.0 2.2 3.0 2.2 11.0 170...264 B
200...240V AC (-15%, +10%) – 3-Phase Input, 0...230V 3-Phase Output
25B-B2P5N104 0.5 0.4 0.5 0.4 2.5 170...264 A
25B-B5P0N104 1.0 0.75 1.0 0.75 5.0 170...264 A
25B-B8P0N104 2.0 1.5 2.0 1.5 8.0 170...264 A
25B-B011N104 3.0 2.2 3.0 2.2 11.0 170...264 A
25B-B017N104 5.0 3.7 5.0 3.7 17.5 170...264 B
25B-B024N104 7.5 5.5 7.5 5.5 24.0 170...264 C
25B-B032N104 10.0 7.5 10.0 7.5 32.2 170...264 D
25B-B048N104 15.0 11.0 15.0 11.0 48.3 170...264 E
25B-B062N104 20.0 15.0 15.0 11.0 62.1 170...264 E
380...480V AC (-15%, +10%) – 3-Phase Input, 0...460V 3-Phase Output
(1)
25B-D1P4N104 0.5 0.4 0.5 0.4 1.4 323...528 A
25B-D2P3N104 1.0 0.75 1.0 0.75 2.3 323...528 A
25B-D4P0N104 2.0 1.5 2.0 1.5 4.0 323...528 A
25B-D6P0N104 3.0 2.2 3.0 2.2 6.0 323...528 A
25B-D010N104 5.0 4.0 5.0 4.0 10.5 323...528 B
25B-D013N104 7.5 5.5 7.5 5.5 13.0 323...528 C
25B-D017N104 10.0 7.5 10.0 7.5 17.0 323...528 C
25B-D024N104 15.0 11.0 15.0 11.0 24.0 323...528 D
25B-D030N104 20.0 15.0 15.0 11.0 30.0 323...528 D
