Access Procedures 3-35
12. Remove the screws that secure the Rectifying Module to the power
structure and remove the Rectifying Module.
13. Remove the screws that secure the Output Power Module to the power
structure, and remove the Output Power Module.
Installation
Install the Output Power Module in reverse order of removal, while
referring to Torque Specifications on page 3-1
.
Rectifying Module
Output Power Module
