Allen-Bradley Studio 5000 Logix Emulate Programming Manual

Design a sequential function chart
Chapter 1
Rockwell Automation Publication 1756-PM006I-EN-P - February 2018 33
The transition is the physical conditions that must occur or change in order to go
to the next step.
Transitions occur in these structures.
For this structure Make sure that
Sequence A transition is between each step.
Selection branch Transitions are inside the horizontal lines.
Simultaneous branch Transitions are outside the horizontal lines.
Define the transition
conditions
