ARRANGEMENT OF THE MAIN ELEMENTS
KEY
1) Rear brake fluid reservoir
2) BAG HOOK
3) Helmet compartment
4) Seat lock
5) Air filter
6) Engine oil level / filler
plug
7) Centre stand
8) Converter air scoop
9) Left passenger footpeg
10) Side stand
11) Left inspection cover
12) Expansion tank
13) Coolant expansion tank plug
1 212 13 3 4
567891011
125 250
500
500
