use and maintenance Atlantic 125/250/500 Sprint
70
NOTE Insert the bulb (5) into the bulb
holder (6), so that the two pins slide into
the slots in the holder.
u Fit a new bulb of equal rating.
u Reverse removal procedure to install the
bulb.
CHANGING THE TAIL LIGHT
BULBS
Carefully read page 68 (BULBS).
The tail light accommodates the following
bulbs:
– Two parking light/brake light bulbs (1).
– Two rear direction indicator bulbs (2).
NOTE The following information applies
to both direction indicators.
To change the bulbs:
u Unscrew the two retaining screws (3)
and remove lens (4).
CAUTION
Proceed with care.
Do not damage the tabs and/or their
seats.
2
1
2
1
4
3
APRum_ATLANT125#02_##uk.book Page 70 Tuesday, March 14, 2006 5:15 PM
