use and maintenance Atlantic 125/250/500 Sprint
20
TOOL KIT
The tool kit (1) is fixed inside the
helmet/glove compartment under the seat.
To reach the crash helmet case, proceed
as follows:
Release the seat, see page 20
(UNLOCKING/LOCKING THE SEAT).
The tool kit includes:
– 6x128 Phillips/hexagon screwdriver with
handgrip;
– 2.5 mm Allen wrench;
– 16x140 spark plug socket with 8.5 4-hole
gasket;
– 8 mm combination wrench;
– 8x120 mm rod.
The tool kit includes:
– double-ended crosshead/flat-blade
screwdriver;
– handle for screwdriver;
– 8 mm combination wrench;
– 16x70 mm socket wrench with hexagon;
– 13 mm combination wrench;
– pin wrench with square pin;
– tool case.
UNLOCKING/LOCKING THE SEAT
u Insert the key (2) into the seat lock.
u Press and turn the key counter
clockwise.
u To lock the seat, lower and press it
(without exerting too much pressure),
thus making the lock snap shut.
WARNING
Before leaving, make sure that the seat
is properly locked.
1
125 250
500
2
