47
use and maintenance Atlantic 125/250/500 Sprint
ADDITIONAL CASE
Position the vehicle on the centre stand.
u Remove the protective cover (1).
u Fit the case mounting plate (2) and
tighten the four screws (3).
u Locate the front end (A) of the case to
the support on the mounting plate.
Press down the rear end (B) of the case
moderately until locking it in place.
CAUTION
Ensure that the case is securely in
place.
1
3
2
B
A
APRum_ATLANT125#02_##uk.book Page 47 Tuesday, March 14, 2006 5:15 PM
