use and maintenance Atlantic 125/250/500 Sprint
12
LOCATION OF INSTRUMENTS/CONTROLS
LOCATION OF INSTRUMENTS/CONTROLS - KEY
1) Left rear-view mirror
2) Instruments and indicators
3) Right rear-view mirror
4) Throttle grip
5) Front brake lever
6) Electrical controls on the right side of
the handlebar
7) Ignition switch/steering lock
(--)
8) Electrical controls on the left side of the
handlebar
9) Combined brake lever (front and rear)
ITI
45689
1 32
7
APRum_ATLANT125#02_##uk.book Page 12 Tuesday, March 14, 2006 5:15 PM
