use and maintenance Atlantic 125/250/500 Sprint
60
ADJUSTING THE THROTTLE
CONTROL
Carefully read page 39
(MAINTENANCE).
There should be 2 - 3 mm free play in the
throttle twistgrip (measured at twistgrip
edge).
If this is not the case, proceed as follows:
u Position the vehicle on the centre stand.
u Withdraw the protection (6).
u Loosen the lock nut (7).
u Rotate the adjuster (8) until achieving
the specified free play.
u When finished, tighten the lock nut (7) and
check free play again.
u Refit the protection (6).
WARNING
When finished, turn the handlebar to
make sure its movement does not affect
the engine idle rpm and check that the
throttle grip - when opened and then
released - returns smoothly to the closed
position.
SPARK PLUG
Carefully read page 39
(MAINTENANCE).
Check the spark plug every time a
scheduled maintenance service is
performed.
At regular intervals, remove the spark plug
and clean off any carbon deposits or
replace as required.
To reach the spark plug:
u Remove the right inspection
cover, see page 57 (REMOVING THE
RIGHT AND LEFT INSPECTION
COVERS).
u Remove the left inspection cover,
see page 57 (REMOVING THE RIGHT
AND LEFT INSPECTION COVERS).
8 7 6
1
125 250
125 250
500
