17
use and maintenance Scarabeo 500
KEY CONTROLS
CONTROLS ON THE LEFT SIDE OF THE HANDLEBAR
NOTE The electric components work only when the ignition
switch is in position
“”.
1) HORN BUTTON ( )
Press it to operate the horn.
2) DIRECTION INDICATOR SWITCH ( )
Move the switch to the left in order to signal your intention to
turn left; move the switch to the right to signal a right turn.
Press the switch at the centre to cancel the signal.
The indicators reset automatically after 40 seconds or after the
vehicle has covered 500 m. The automatic reset system only
operates when the vehicle is in motion.
3) DIMMER SWITCH ( - ) / HIGH BEAM FLASHER
(PASSING )
Set the dimmer switch to
“”, to turn on the low beam, set it
to
“” to turn on the high beam.
Push the dimmer switch to position (PASSING ) to flash the
high beam.
NOTE Release the switch to stop the flasher.
4) MODE BUTTON (MODE)
Press it repeatedly to select the various indications provided
by the multifunction display.
5) HAZARD BUTTON ( )
OPERATION Press the button to activate the emergency stop
blinker. When the blinker is on, it is possible to turn the ignition
switch to and extract the key.
DEACTIVATION
Insert the key into the ignition switch and turn it to position “ ”,
press the HAZARD button again to turn off the blinker.
MODE
PA
S
S
IN
G
2 3 5
1
4
