use and maintenance Scarabeo 500
66
PARKING LIGHT BULBS
CAUTION
Do not pull on the wiring to remove the
bulb holder.
◆ Working from underneath the headlight,
grasp the bulb holder (1) and pull to
extract from its seat.
◆ Remove the parking light bulb (2) and fit
a new bulb of equal rating.
REPLACING THE TAIL LIGHT
BULBS
Read page 64 (BULBS) carefully.
The tail light accommodates two parking
light/brake light bulbs (3).
Replacement:
◆ Release the two retaining screws (3) and
remove the lens (4).
CAUTION
Do not pull on or force the wiring during
the removal procedure.
CAUTION
Proceed carefully.
Do not damage the tabs and their seats.
◆ Press on the sides of the inner lens (5)
lightly and remove the lens.
◆ Rotate anticlockwise and extract bulb (6)
from the reflector (7).
1 2
4
3
5
67
