use and maintenance Scarabeo 500
60
REMOVING THE BATTERY COVER
Read page 59 (BATTERY).
NOTE Place the vehicle on firm and
level ground.
◆ Open the glove compartment (1), see
page 24 (GLOVE COMPARTMENT).
◆ The battery has a snap-on cover (2).
Prise off the cover with a screwdriver,
but proceed gently to avoid damage.
◆ Remove the battery cover (2).
CHECKING AND CLEANING THE
BATTERY LEAD CONNECTIONS
AND TERMINALS
◆ Remove the battery cover, page 60
(REMOVING THE BATTERY) at the
side.
◆ Ensure that the ignition switch is in the
“ ” position.
◆ Make sure that the battery lead connections
(3) and the battery terminals (4) are:
– in good condition (i.e. show no corrosion
deposits);
– coated with neutral grease or Vaseline.
If necessary:
◆ disconnect the negative cable (-) first
and then the positive (+) cable.
◆ Clean off any corrosion deposits with a
wire brush.
◆ Reconnect the positive cable (+) first and
then the negative cable (-).
◆ Coat the battery lead connections and
terminals with neutral grease or Vaseline.
REMOVING THE BATTERY
◆ Remove the battery cover, page 60
(REMOVING THE BATTERY COVER)
at the side.
◆ Remove the battery breather hose (5).
◆ disconnect the negative cable (-) first
and then the positive (+) cable.
◆ Unscrew the screw (6) and remove the
battery mounting bracket (7).
◆ Remove the battery (8) from its seat and
place it on a flat surface, in a cool, dry place.
WARNING
Once removed, store the battery in a
safe place, out of the reach of children.
◆ Refit the battery cover, page 60
(REMOVING THE BATTERY COVER)
at the side.
WARNING
Handle with care when the breather
hose is removed, or battery fluid might
spill out.
2
1
3
4
6
8
7
5
