use and maintenance Scarabeo 500
REMOVING THE RIGHT AND LEFT
INSPECTION COVERS
Read page 41 (MAINTENANCE)
carefully.
◆ Place the vehicle on the centre stand.
◆ Release and remove the six retaining
screws (1) of the inspection covers.
◆ Release and remove the two lower
retaining screws of the passenger
footrests.
CAUTION
Proceed with the utmost care. Do not
damage the lower fixing tabs and their
seats. Handle plastic and paint-finished
components with care to avoid
scratching or damage.
CAUTION
Ensure that the tabs locate correctly
into their seats on refitting.
REMOVING THE WINDSHIELD
Read page 41 (MAINTENANCE)
carefully.
◆ Place the vehicle on the centre stand.
◆ Release and remove the four retaining
screws (2) of the windshield guard (3).
CAUTION
Pay attention to the fixing tab clips (4).
They might come loose during removal.
◆ Release and remove the four screws (5)
securing the windshield to the vehicle.
◆ Remove the windshield (6).
1
1
2
2
3
4
5
4
5
6
4
5
4
5
