71
use and maintenance Scarabeo 500
TECHNICAL DATA
Dimensions
Max length 2310 mm
Max width 785 mm
Max height (incl. windshield) 1435 mm
Rider saddle height 800 mm
Wheelbase 1590 mm
Minimum ground clearance 170 mm
Weight in running order 234 Kg
Engine
Type 4-stroke single-cylinder engine, 4 valves per cylinder, single overhead
camshaft operated via a chain on flywheel side.
No. of valves 4
No. of cylinders 1
Total displacement 460 cu cm
Bore/stroke 92 mm / 69 mm
Compression ratio 10.5 : 1
Starting Electric starter
Engine idling speed 1450 ± 50 rpm
Clutch Automatic dry centrifugal clutch
Gearbox Automatic
Lubricating system Forced circulation by trochoidal pump accommodated inside crankcase, oil
filter and pressure regulation through bypass valve
Cooling system Liquid cooling, forced circulation by centrifugal pump
Transmission
Converter Stepless automatic
Primary V-belt
Secondary Gears
Total engine/wheel ratio minimum1:14.083
maximum1:5.406
