use and maintenance Scarabeo 500
12
ARRANGEMENT OF THE MAIN ELEMENTS
KEY
1) Expansion tank
2) Coolant expansion tank plug
3) Rear brake fluid reservoir
4) Air cleaner
5) Rear top box
6) Converter air filter cover
7) Passenger left footrest
8) Side stand
9) Centre stand
10) Spark plug
11) Left inspection cover
12) Horn
3 5
2
1
12 11 10 9 8 7 6
4
