MediaPack SIP User’s Manual 2. MediaPack Physical Description
Version 4.6 23 June 2005
2 MediaPack Physical Description
This section provides detailed information on the hardware, the location and functionality of the
LEDs, buttons and connectors on the front and rear panels of the MP-1xx (refer to Section
2.1
below) and MP-11x (Section
2.2 on page 27) gateways.
For detailed information on installing the MediaPack, refer to Section
3 on page 29.
2.1 MP-1xx Physical Description
2.1.1 MP-1xx Front Panel
Figure 2-1 and Figure 2-2 illustrate the front layout of the MP-108 (almost identical on MP-104
and MP-102) and MP-124 respectively. Refer to Section
2.1.1.1 for meaning of the front panel
buttons; refer to Section
2.1.1.2 for functionality of the front panel LEDs.
Figure
2-1: MP-108 Front Panel
Figure
2-2: MP-124 Front Panel
Reset Button
Reset Button
