Remove front wheel stand.

Slide the brake calipers onto

the brake rotors.

Install screws 2 on left and

right with appropriate torque.

Brake caliper on fork leg

21 lb/ft (28 Nm)

ATTENTION

Contact between the wheel

speed sensor cable and the

brake disc.

Sensor cable wearing through.

Make sure that sensor cable is

routed correctly.

Insert wheel speed sensor in

bore and install screw 1.

Remove adhesive tape from

wheel rim.

Firmly pull the handbrake lever

until the pressure point is per-

ceptible, and repeat this opera-

tion several times.

Mount front wheel cover and

install screws 1 and 2 on right

and left.

Calibrating ASC ( 52).

Removing rear wheel

Make sure ground is level and

firm and place Maxi-Scooter on

its center stand.

CAUTION

Hot exhaust system.

Burn hazard

Do not touch hot exhaust

system.

Remove the screw 1.

Maintenance

Questions and Answers:

Need help?

Do you have a question about the BMW C650GT and is the answer not in the manual?

BMW C650GT Specifications

General

Displacement	647 cc
Power	60 hp (44 kW) at 7, 500 rpm
Torque	63 Nm at 6, 000 rpm
Transmission	CVT
ABS	Standard
Wheelbase	1, 591 mm
Top Speed	180 km/h
Fuel System	Electronic fuel injection
Seat Height	805 mm
Weight	261 kg
Front Suspension	Upside-down fork, 40 mm
Rear Suspension	Swing arm, spring pre-load adjustable
Front Brake	Dual 270 mm discs, two-piston floating calipers
Rear Brake	Single disc, 270 mm
Width	916 mm
Engine Type	Liquid-cooled, 4-stroke in-line twin-cylinder engine, four valves per cylinder, two overhead camshafts
