Remove screw 1 and take
wheel speed sensor out of
bore.
Mask off areas of wheel rim
that could be scratched in the
process of removing the brake
calipers.
ATTENTION
Pressing together the brake
pads with the brake caliper
removed.
The brake caliper cannot be
mounted over the brake disc.
Do not operate the brake
lever with the brake caliper
removed.
Remove screws 2 of brake
calipers on left and right.
Push brake pads 3 apart
slightly by turning brake
caliper 4 back and forth against
brake rotor 5.
Carefully pull brake calipers
back and outward to remove
them from brake rotors.
Make sure ground is level and
firm and place Maxi-Scooter on
its center stand.
Raise Maxi-Scooter at
front, preferably using a
BMW Motorrad front wheel
stand, until the front wheel
rotates freely.
Mount front wheel stand
( 101).
Loosen the clamping bolts 1
on the right.
Remove quick-release axle 2
while supporting wheel.
Roll front wheel forward to re-
move it.
8
96
z Maintenance

BMW C650GT Specifications

General

Displacement	647 cc
Power	60 hp (44 kW) at 7, 500 rpm
Torque	63 Nm at 6, 000 rpm
Transmission	CVT
ABS	Standard
Wheelbase	1, 591 mm
Top Speed	180 km/h
Fuel System	Electronic fuel injection
Seat Height	805 mm
Weight	261 kg
Front Suspension	Upside-down fork, 40 mm
Rear Suspension	Swing arm, spring pre-load adjustable
Front Brake	Dual 270 mm discs, two-piston floating calipers
Rear Brake	Single disc, 270 mm
Width	916 mm
Engine Type	Liquid-cooled, 4-stroke in-line twin-cylinder engine, four valves per cylinder, two overhead camshafts
