BMW C650GT - General View, Left Side

General view, left side
1 Brake-fluid reservoir for
rear brake ( 90)
2 Fuel filler opening (under
the tank cover) ( 73)
3 Adjustable backrest
( 60)
4 Adjusting spring preload
( 63)
5 Oil filler opening and oil
dipstick (under the foot-
board) ( 84)
2
11
z Overviews
