BMW C650GT User Manual

Lay on cover and install
screw 1.
Mount step plate support 1.
Wheel rims and tires
Checking wheel rims
Make sure ground is level and
firm and place Maxi-Scooter on
its center stand.
Subject wheel rims to visual
inspection for defects.
Have damaged rims checked
and, if necessary, replaced
by a specialist service facil-
ity, preferably an authorized
BMW Motorrad retailer.
Check tire tread depth
WARNING
Riding with heavily worn
tyres
Risk of accident due to poorer
rideability
If necessary, replace the tyres
before the legally specified
minimum tread depth is
reached.
Make sure ground is level and
firm and place Maxi-Scooter on
its center stand.
Measure tire tread depth in
main tread grooves with wear
indicators.
NOTICE
Tread wear marks are integrated
into the main grooves on every
tire. If the tire tread has worn
down to the level of the marks,
the tire is completely worn. The
locations of the marks are indi-
cated on the edge of the tire, e.g.
by the letters TI, TWI or by an
arrow.
When the minimum tread depth
is reached:
Replace the worn tires.
8
93
z Maintenance

BMW C650GT Specifications

General

Displacement	647 cc
Power	60 hp (44 kW) at 7, 500 rpm
Torque	63 Nm at 6, 000 rpm
Transmission	CVT
ABS	Standard
Wheelbase	1, 591 mm
Top Speed	180 km/h
Fuel System	Electronic fuel injection
Seat Height	805 mm
Weight	261 kg
Front Suspension	Upside-down fork, 40 mm
Rear Suspension	Swing arm, spring pre-load adjustable
Front Brake	Dual 270 mm discs, two-piston floating calipers
Rear Brake	Single disc, 270 mm
Width	916 mm
Engine Type	Liquid-cooled, 4-stroke in-line twin-cylinder engine, four valves per cylinder, two overhead camshafts
