BMW C650GT User Manual

Replace a defective fuse in the
fuse carrier with a fuse of the
required current level.
NOTICE
An overview of the fuse assign-
ment and the required amper-
ages is provided in the chapter
"Technical Data". The numbers
in the graphic match the fuse
numbers.
Install fairing side panel
( 111).
Light sources
Replacing bulbs for low-
beam and high-beam
headlight
Make sure ground is level and
firm and place Maxi-Scooter on
its center stand.
Switch off ignition.
To replace the light source for
the low-beam headlight, re-
move the right-hand fairing
side panel.
To replace the light source for
the high beam, remove the
left-hand fairing side panel.
Replace the light source from
below. Removing the fairing
side panel improves the align-
ment.
Remove the cover 1 to replace
the light source for the high
beam.
Remove the cover 2 to replace
the light source for the low-
beam headlight.
8
104
z Maintenance

BMW C650GT Specifications

General

Displacement	647 cc
Power	60 hp (44 kW) at 7, 500 rpm
Torque	63 Nm at 6, 000 rpm
Transmission	CVT
ABS	Standard
Wheelbase	1, 591 mm
Top Speed	180 km/h
Fuel System	Electronic fuel injection
Seat Height	805 mm
Weight	261 kg
Front Suspension	Upside-down fork, 40 mm
Rear Suspension	Swing arm, spring pre-load adjustable
Front Brake	Dual 270 mm discs, two-piston floating calipers
Rear Brake	Single disc, 270 mm
Width	916 mm
Engine Type	Liquid-cooled, 4-stroke in-line twin-cylinder engine, four valves per cylinder, two overhead camshafts
