Fit the screw 1.
Diagnostic connector
Removing the diagnostic
connector
The diagnostic connector is lo-
cated under the fairing side panel
at the front right.
NOTICE
The diagnostic connector for
OBD may only be detached by
Service engineers or in a work-
shop by qualified personnel in
accordance with the specifica-
tions of the vehicle and used
by authorized personnel. The
vehicle may otherwise suffer
malfunction.
Removing fairing side panel
( 110).
Press the locks 1 together.
Remove the diagnostic con-
nector 2 from the bracket 3.
The diagnosis and information
system interface can be con-
nected at the diagnostic con-
nector 2.
Installing the diagnostic
connector
Disconnect the diagnosis and
information system interface.
Seat diagnostic connector 2
into the bracket 3.
The locks 1 engage.
Install fairing side panel
( 111).
8
112
z Maintenance

BMW C650GT Specifications

General

Displacement	647 cc
Power	60 hp (44 kW) at 7, 500 rpm
Torque	63 Nm at 6, 000 rpm
Transmission	CVT
ABS	Standard
Wheelbase	1, 591 mm
Top Speed	180 km/h
Fuel System	Electronic fuel injection
Seat Height	805 mm
Weight	261 kg
Front Suspension	Upside-down fork, 40 mm
Rear Suspension	Swing arm, spring pre-load adjustable
Front Brake	Dual 270 mm discs, two-piston floating calipers
Rear Brake	Single disc, 270 mm
Width	916 mm
Engine Type	Liquid-cooled, 4-stroke in-line twin-cylinder engine, four valves per cylinder, two overhead camshafts
