BMW C650GT User Manual

on the road surface. The display
automatically switches from any
other mode to the temperature
reading when the temperature
drops below this threshold for
the first time.
Tire inflation pressures
with Tire Pressure Control
(TPC/RDC)
OE
The displayed tire inflation pres-
sures refer to a tire air temper-
ature of 68 °F (20 °C). The fig-
ure on the left side 1 indicates
the front tire's inflation pressure,
while the figure on the right 2
shows the inflation pressure in
the rear tire. Immediately af-
ter switching on the ignition,
: is displayed, as the
transmission of the tire pres-
sure values does not begin until
a speed of 19 mph (30 km/h) is
exceeded for the first time.
If the general warning
light 4 flashes red and if
the symbol 3 is also displayed,
then a warning indicator is
concerned. The upper arrow
next to the tire symbol indicates
a problem at the front wheel,
and the lower arrow indicates a
problem at the rear wheel.
Further information on
BMW Motorrad TPC/RDC can
be found from page ( 81)
onwards.
Oil level indicator
The oil level display 1 provides
information on the oil level in the
engine. This display can only
be activated when the vehicle is
stopped.
The conditions required for using
the oil level display are as follows:
Engine at normal operating
temperature.
Engine idling for at least ten
seconds.
Side stand retracted.
3
23
z Displays

BMW C650GT Specifications

General

Displacement	647 cc
Power	60 hp (44 kW) at 7, 500 rpm
Torque	63 Nm at 6, 000 rpm
Transmission	CVT
ABS	Standard
Wheelbase	1, 591 mm
Top Speed	180 km/h
Fuel System	Electronic fuel injection
Seat Height	805 mm
Weight	261 kg
Front Suspension	Upside-down fork, 40 mm
Rear Suspension	Swing arm, spring pre-load adjustable
Front Brake	Dual 270 mm discs, two-piston floating calipers
Rear Brake	Single disc, 270 mm
Width	916 mm
Engine Type	Liquid-cooled, 4-stroke in-line twin-cylinder engine, four valves per cylinder, two overhead camshafts
