Insert socket 4 into spacer 3.
Place spacer 3 onto number-
plate holder 2.
Fit the screw 1.
Jump-starting
ATTENTION
Current too strong when
jump-starting the Maxi-
Scooter
Cable fire or damage to the vehi-
cle electronics
Jump start the Maxi-Scooter
exclusively using the battery
terminals, not the power
socket.
ATTENTION
Contact between crocodile
clips of jump leads and mo-
torcycle.
Danger of short circuit
Use jump leads fitted with fully
insulated crocodile clips at both
ends.
ATTENTION
Jump-starting with a voltage
higher than 12 V.
Damage to the motorcycle's
electronics.
The battery of the donor ve-
hicle must have a voltage of
12 V.
Make sure ground is level and
firm and place Maxi-Scooter on
its center stand.
Removing fairing side panel
( 110).
Begin by connecting one end
of red jumper cable to positive
terminal of your motorcycle and
other end to positive battery
terminal of other vehicle.
Begin by connecting one end
of black jumper cable to nega-
tive terminal of your motorcycle
with a suitable grounding point
or to negative battery terminal
of other vehicle.
8
107
z Maintenance

BMW C650GT Specifications

General

Displacement	647 cc
Power	60 hp (44 kW) at 7, 500 rpm
Torque	63 Nm at 6, 000 rpm
Transmission	CVT
ABS	Standard
Wheelbase	1, 591 mm
Top Speed	180 km/h
Fuel System	Electronic fuel injection
Seat Height	805 mm
Weight	261 kg
Front Suspension	Upside-down fork, 40 mm
Rear Suspension	Swing arm, spring pre-load adjustable
Front Brake	Dual 270 mm discs, two-piston floating calipers
Rear Brake	Single disc, 270 mm
Width	916 mm
Engine Type	Liquid-cooled, 4-stroke in-line twin-cylinder engine, four valves per cylinder, two overhead camshafts
