Fuses

Removing fuse

The fuses are located under the

fairing side panel at the front

right.

ATTENTION

Bypassing defective fuses.

Risk of short circuit and fire.

Replace defective fuses with

new fuses.

Switch off ignition.

Removing fairing side panel

( 110).

Pull defective fuse out of fuse

box 1 or out of fuse holder 2

with tool from onboard toolkit.

To open the fuse box, press

the locking levers 3 together

and remove the cover.

NOTICE

If the fuses blow frequently, have

the electrical system checked by

an authorized specialized work-

shop, preferably an authorized

BMW Motorrad retailer.

Installing fuse

Replace each defective fuse

from the fuse box with a fuse

of the correct amperage rating.

Close the cover.

Locking device audibly en-

gages.

103

Maintenance
