Backrest

Adjust backrest

The backrest is delivered in the

rearmost of three possible posi-

tions.

Open the seat 3.

Remove screws 1 and 2.

Remove backrest.

Position the mountings 4 in

the required position above the

seat bench 3.

Tighten the shorter screws 1

five turns.

Tighten the longer screws 2

five turns.

Repeat this sequence until

the backrest is firmly secured.

Here, tighten the screws only

hand-tight.

Backrest on seat bench

1 lb/ft (2 Nm)

Close the seat 3.

Windshield

Automatic park- and drive

position

ATTENTION

Windshield collision in auto-

matic drive.

Scratches, cracks and broken

windshield.

Do not keep any items in the

driving area.

Note or remove obstacles.

Setting

Questions and Answers:

Need help?

Do you have a question about the BMW C650GT and is the answer not in the manual?

BMW C650GT Specifications

General

Displacement	647 cc
Power	60 hp (44 kW) at 7, 500 rpm
Torque	63 Nm at 6, 000 rpm
Transmission	CVT
ABS	Standard
Wheelbase	1, 591 mm
Top Speed	180 km/h
Fuel System	Electronic fuel injection
Seat Height	805 mm
Weight	261 kg
Front Suspension	Upside-down fork, 40 mm
Rear Suspension	Swing arm, spring pre-load adjustable
Front Brake	Dual 270 mm discs, two-piston floating calipers
Rear Brake	Single disc, 270 mm
Width	916 mm
Engine Type	Liquid-cooled, 4-stroke in-line twin-cylinder engine, four valves per cylinder, two overhead camshafts
