BMW C650GT User Manual

Make sure that the topcase
handle 2 is folded out and the
key in the topcase lock is in
the RELEASE position.
Insert the Topcase in the Top-
case carrier at the front.
Pull the release lever 4 toward
the rear while simultaneously
inserting the Topcase in the
Topcase carrier at the rear.
Close Topcase handle 2.
If necessary, turn the key in
the topcase lock to the CLOSE
position and remove.
Maximum payload and
maximum speed
Observe maximum payload and
top speed as indicated on label
in Topcase.
If you cannot find your combi-
nation of motorcycle and top-
case on the label, contact your
BMW Motorrad Retailer.
The following values apply to the
combination described here:
Maximum speed limit for
driving with a Topcase
max 112 mph (max 180 km/h)
Topcase payload
max 11 lbs (max 5 kg)
Scooter lock
with Scooter lock
OA
Locking motorcycle
Thread the rear end piece 1 of
the Scooter lock into the rear
mounting from below.
Then turn end piece toward
front.
9
117
z Accessories

BMW C650GT Specifications

General

Displacement	647 cc
Power	60 hp (44 kW) at 7, 500 rpm
Torque	63 Nm at 6, 000 rpm
Transmission	CVT
ABS	Standard
Wheelbase	1, 591 mm
Top Speed	180 km/h
Fuel System	Electronic fuel injection
Seat Height	805 mm
Weight	261 kg
Front Suspension	Upside-down fork, 40 mm
Rear Suspension	Swing arm, spring pre-load adjustable
Front Brake	Dual 270 mm discs, two-piston floating calipers
Rear Brake	Single disc, 270 mm
Width	916 mm
Engine Type	Liquid-cooled, 4-stroke in-line twin-cylinder engine, four valves per cylinder, two overhead camshafts
