ctrlX SAFETY "SafeMotion"
Machine acceptance test
Bosch Rexroth AG
R911404905,
Edition 02
10.5.9 Signal control of outputs
The “Signal control of outputs“ dialog can be opened in
ctrlX DRIVE Engineering via the
“... 🠂 Machine acceptance test 🠂 Signal
control of outputs” node.
The dialog is not provided if no source signal has been assigned to the safe
output in "P‑0‑3335.0.2, SMO: Signal control of outputs discrete, bit number“.
In this dialog, it is possible to check whether the signal applied to the safe local
output is correctly processed.
Fig. 116: Machine acceptance test: Signal control of outputs
Parameters involved:
● P‑0‑3335.0.1, SMO: Signal control of outputs discrete, IDN assignment
● P‑0‑3335.0.2, SMO: Signal control of outputs discrete, bit number
Commissioning
