ctrlX SAFETY "SafeMotion"
Specifying the digital/analog inputs/outputs
Bosch Rexroth AG
R911404905,
Edition 02
13.5.2 Digital inputs (safety technology SafeMotion)
Table 52: Data
Data Unit min. max.
Allowed input voltage V -3 30
High V 15 30
Low V -3 5
Input current (at high state) mA 2 5
Delay time µs 500
