8.6.4 Status Indicators
SERCOS Ring H4
LED Description
green Data is received
yellow Data is transmitted
red Distortion or line-break
Fig.8-8: Status indicators for SERCOS ring H4
Fast I/Os H5
LED Description
yellow 1 Peripherals error
yellow 2 Not used
yellow 3 Host error
Fig.8-9: Status indicators for fast I/Os H5
Fast I/Os H6
LED Description
green Ready for operation
yellow ???
red Error
Fig.8-10: Status indicators for fast I/Os H6
8.7 Additional SERCOS Rings
8.7.1 General Information
On the NC multifunction card one pair of fibre optics cable is available for the
first SERCOS ring. The interface adapters +NCMZ003 (for one additional
SERCOS ring) and +NCMZ004 (for two additional SERCOS rings) are available
for connecting further SERCOS rings.
Project Planning Manual | Rexroth MTA 200 Electric Drives
and Controls
| Bosch Rexroth AG 97/135
NC Multifunction Card NCM02
