Brother JS1410 User Manual

4 - 8
Adjustment
Adjustment
Adjustment Presser foot hole / Needle plate hole position (front/back)
[Standard]
The front/back direction of hole on the presser foot and the needle plate should be matched.
[Adjustment]
1. Lower the presser foot lifter and lower the presser foot.
2. Insert the screwdriver from the rear cover hole to turn the screw, and adjust the position of the presser foot
hole and the needle plate hole in the front/back direction.
*Key point
• Loosen the screw. (turn to the direction of “A”.) → Move the needle to the front side. (A)
• Tighten the screw. (turn to the direction of “B”.) → Move the needle to the rear side. (B)
Presser foot lifter
Presser foot
Cup screw M3X20
Rear cover
Screwdriver
Back side view
Screw
Needle plate hole
Presser
foot hole
Presser foot
B
A
AB
Needle plate
