6 - 3
Special Instructions
of Wiring
Special Inst
r
uctions
of Wiring
Special Instructions
of Wiring
LED lead wire
1.
Wiring of LED lead wire
Wire the LED lead wire within t
he range of the dashed li
ne when
wiring the LED lead wire to the rear side of arm bed.
Screw
LED lamp
PCB
LED lead wire
Connector
Screw
Cord clamps
PCB
Set the cord clamp to the LED lead wire, and secure it
to the arm bed with the screw correctly. (2 locations)
Be careful not to catch
the LED lead wire,
because the ribs of
rear
cover contact here.
Be careful not to catch
the LED lead
wire,
because the ribs of rear
cover contact here.
149
151
