3-56
Confidential
(12)Remove the Second side CIS unit from the Lower doc chute ASSY.
(13)Remove the CIS spacer from the Second side CIS unit.
Fig. 3-45
Routing of harnesses: See “ ADF unit/Document scanner unit”.
Lower doc chute ASSY
Second side CIS unit
CIS spacer
CIS spacer
13
13
12
7
