2.2 Document Feeding Path/Recording Paper Feeding Path
2.2.1 Document Feeding Path
Fig. 2-3
2.2.2 Recording Paper Feeding Path
Fig. 2-4
Document feeding path during ADF scanning
Feeding path from MP tray
Feeding path
Feeding path
during duplex-printing
from Paper tray#1
Feeding path
from Paper tray#2
